ZKTC VACUUM TRIGGER TUBE GTVAC--DZCF2021X

Model No.︰	GTVAC--DZCF2021
Brand Name︰	GTVAC
Country of Origin︰	China
Unit Price︰	-
Minimum Order︰	10 pc

Total 120 Related Items

Product Description

The vacuum trigger tube is a kind of fast pulse switches applicable for high voltage and current.It offers a number of advantages,such as high with stand voltage,small in size.no noise,fast ignition and fast recovery,etc.So,it is widely used as the HV,frequently-operated,pulse switch in the discharge units of a capacitor bank and the laser systems.

Price Terms︰	FOB Wuxi
Specifications︰	Model DZCF2021X DZCF2016T Rated working voltage (kV) twenty twenty Peak current (KA) thirty-five twenty-five Quantity of electricity (c) ten ten Triggering energy (J) 0.05-1 0.06-1 Triggering voltage (kV) 0.5-3 0.3-3.5 Inductance (Uh) < zero point zero five < zero point one Minimum operating voltage at gap Min Working Voltageacross Mai Gap(V) < fifty < fifty Voltage drop of tube (V) < fifty < fifty Cutoff current (a) < ten < ten Max working frequency (kHz) fifteen ten Operating life (Times) > one hundred and four > one hundred and four Triggering delay (US) zero point zero eight zero point zero six Delay dispersion (US) < zero point zero one < zero point zero two Outline dimensions (mm) Ф sixty-eight × one hundred and fifty-two Ф sixty-eight × one hundred and fifty-two Weight (kg) one point two zero one point five zero Note 1: the typical time is the time between the trigger current reaching 90% of the trigger breakdown current and the anode reaching the maximum current when the working voltage is 0.5-25kv.
Advantages︰	The vacuum trigger tube is a kind of fast pulse switches applicable for high voltage and current.It offers a number of advantages,such as high with stand voltage,small in size.no noise,fast ignition and fast recovery,etc.So,it is widely used as the HV,frequently-operated,pulse switch in the discharge units of a capacitor bank and the laser systems.
Export Markets︰	it is widely used as the HV,frequently-operated,pulse switch in the discharge units of a capacitor bank and the laser systems.
Payment Details︰	Delivery upon payment
Min Order︰	10
Ship Date︰	Two weeks later

Product Image
