Features * tungsten contact for switching power supply * vacuum medium, low contact resistance
*Low leakage current * meets or exceeds mil-r-83725 standard
Price Terms︰
FOB WUXI
Specifications︰
Specification No GTD22A GTD22B Contact configuration SPST-NO A SPST-NC B Test voltage (DC or 50Hz AC peak) Test Voltage （DC or AC 50Hz Peak）kV twenty-eight twenty-eight Rated operating voltage (peak) Rated Operating Voltage(Peak) kV DC or AC 50Hz twenty-five twenty-five AC2.5MHz thirteen AC16MHz ten AC32MHz Rated carrying current (effective value) Rated Carrying Voltage(RMS) A DC or AC 50Hz sixty-five forty-five AC2.5MHz twenty-five AC16MHz ten AC32MHz three Contact resistance (Ω) zero point zero zero five zero point zero one Contact capacitance (PF) Between disconnected contacts Beteween Open Contacts two point five two point five Between contact and housing Open Contacts to Ground two point five two point five Operate time max. (MS) eighteen eighteen Release time max. (MS) twenty twenty Temperature range of temp (℃) - 55~+125 - 55~+125 Shock level, 11ms 1/2sine (peak G's) fifty fifty Vibration, peak 10g's (Hz) 10~500 10~500 Expected mechanical life（ × 106) one one Nominal weight (g) three hundred and thirty three hundred and thirty
Advantages︰
Coil parameter Rated voltage DC (V) twenty-four Maximum pull in voltage max. DC (V) sixteen Release voltage dropout voltage Min.DC(V) three point five Coil resistance (Ω± 10%) one hundred and twenty Features * tungsten contact for switching power supply * vacuum medium, low contact resistance *Low leakage current * meets or exceeds mil-r-83725 standard
