Specification No JPK-6A JPK-6B
Contact configuration SPDT SPDT
Test voltage (DC or 60Hz AC peak)
Test Voltage （DC or AC 60Hz Peak）kV twenty-five twenty-eight
Rated operating voltage (peak)
RatedOperating Voltage(Peak) kV DC or AC 60Hz twenty twenty-five
AC2.5MHz ten -
AC16MHz fifteen -
AC32MHz seven -
Rated load current (peak)
Rated Load Current (Peak) DC or AC 60Hz （A） one hundred and fifty one hundred and ten
AC13.56MHz(kV Peak) seventy-five -
Coil breakdown voltage (60Hz, AC effective value)
Breakdown Voltage (60Hz，RMS) （V） five hundred five hundred
Contact resistance (Ω) zero point zero zero three zero point zero zero five
distributed capacitance
Contact Capacitance（pf） Between disconnected contacts
Beteween Open Contacts five five
Between contact and housing
Open Contacts to Ground five five
Operate time max. (MS) one hundred one hundred
Release time max. (MS) fifteen fifteen
Temperature range of temp (℃) - 55~+125 - 55~+125
Vibration frequency, 55~500 Hz, (peak G's) ten ten
Shock level, 11ms 1/2sine (peak G's) thirty thirty
Vibration, peak 10g's (Hz) 10@
10-500 10@
55-500
Expected mechanical life（ × 106) one one
Nominal weight (g) nine hundred and ninety-two nine hundred and ninety-two
