2C DPDT HV Relays

DPDT relay gt26wf is very suitable for applications requiring high continuous carry. Cas-gtvac20kv DPDT relay gt36wf has a current of up to 150A and a high-power RF circuit requiring low signal loss. The combination of a large number of copper contacts and vacuum dielectrics provides a low and stable 12 milliohm contact.
Resistance refers to low voltage drop in DC circuit and low signal loss in RF circuit.
The gt36wf has two mechanically connected SPDT contacts. This capability is effectively packaged into a size of approximately 7.7 inches × 3.5 inches (19.6 cm × 8.9 cm). The gt36wf is available with 12 VDC or 26.5 VDC coils, which is ideal for driving circuits from 8 VDC to 28 VDC. Special coils are available to meet customer requirements. When you need to know that the contacts of the second group of contacts of the relay can be used as auxiliary contacts.
According to Xia Xia Xia, product manager of high voltage relay cas-gtvac, "we have listened to customers and now can provide low-cost switching solutions for high voltage and high current RF applications. Gt36wf is also very suitable for many DC applications that require high current carrying capacity. The voltage reaches 30000 v. the bipolar double throw form provides twice the circuit access in one relay.
Cas-gtvac20-30 kV DPDT relay gt36wf features
1. small package and large current carrying
2. low stable contact resistance minimizes the loss of RF circuit.
3. DPDT table for increasing circuit capacity
4. threaded high voltage terminal provides convenient and safe connection!
Double pole double throw high-voltage relay, wear-resistant tungsten contact, vacuum medium, can effectively extinguish the arc when disconnected under load, and the coil can be replaced, so that the product functions can be diversified,
Gt30 vacuum relay
Double pole double throw high-voltage relay, wear-resistant tungsten contact, vacuum medium, can effectively extinguish the arc when disconnected under load, and the coil can be replaced, so that the product functions can be diversified,
Wear resistant tungsten contact, vacuum medium, can effectively extinguish arc when disconnected under load
*For load switch application, please consult the factory
*The coil can be replaced to diversify the product functions and meet or exceed the mil-r-83725 standard!
Specification no.gt28sp
Contact configuration2c DPDT
High voltage relay is an automatic switching element with isolation function. It is widely used in remote control, telemetry, communication, automatic control, mechatronics and power electronic equipment. It is one of the most important control elements.
