characteristic
1. Copper contact for switching power supply
2. Low leakage current
3. Vacuum medium, low contact resistance
4 . Meet or exceed mil-r-83725 standard
Specifications︰
Specification No GTD23A GTD23B Contact configuration SPST-NO A SPST-NC B Test voltage (DC or 50Hz AC peak) Test Voltage （DC or AC 50Hz Peak）kV thirty thirty Rated working voltage (peak) Rated Operating Voltage(Peak) kV DC or AC 50Hz twenty-eight twenty-eight AC2.5MHz thirteen AC16MHz ten AC32MHz Rated carrying current (effective value) Rated Carrying Voltage(RMS) A DC or AC 50Hz 110 110 AC2.5MHz twenty-five AC16MHz ten AC32MHz three Contact resistance (Ω) zero point zero zero five zero point zero one Contact capacitance (PF) Between disconnected contacts Beteween Open Contacts two point five two point five Between contact and housing Open Contacts to Ground two point five two point five Operate time max. (MS) eighteen eighteen Maximum release time max. (MS) twenty twenty Temperature range of temp (℃) - 55~+125 - 55~+125 Shock level, 11ms 1/2sine (peak G's) fifty fifty Vibration, peak 10g's (Hz) 10~500 10~500 Expected mechanical life（ × 106) two two Nominal weight (g) two hundred and seventy-three two hundred and seventy-three Coil parameter Rated voltage DC (V) twenty-four Maximum pull in voltage max. DC (V) sixteen Release voltage dropout voltage Min.DC(V) one Coil resistance (Ω± 10%) one hundred and twenty
Advantages︰
characteristic 1. Copper contact for switching power supply 2. Low leakage current 3. Vacuum medium, low contact resistance 4 . Meet or exceed mil-r-83725 standard
