Specification No JPK-11/008 Contact form 2C Contact arrangement DPDT Test voltage (DC or 50Hz AC peak) Test Voltage （DC or AC 50Hz Peak）kV twenty-two Rated operating voltage (peak) Rated Operating Voltage(Peak) kV DC or AC 50Hz eighteen AC2.5MHz fifteen AC16MHz twelve AC32MHz Rated carrying current (effective value) Rated Carrying Voltage(RMS) A DC or AC 50Hz seventy-five AC2.5MHz thirty-five AC16MHz twenty-two AC32MHz eight Contact resistance (Ω) zero point zero one distributed capacitance Contact Capacitance (pf) Beteween open contacts three Open contacts to ground three point five Operate time max. (MS) thirty Release time max. (MS) eight Temperature range of temp (℃) - 55~+125 Shock level, 11ms 1/2sine (peak G's) fifty Vibration, peak 10g's (Hz) 10~500 Expected mechanical life（ × 106) one Nominal weight (g) three hundred and eighty
Advantages︰
Coil parameter Rated voltage DC (V) twenty-seven 24(26.5) Maximum pull in voltage max. DC (V) sixteen sixteen Release voltage dropout voltage Min.DC(V) 1~10 1~10 Coil resistance (Ω± 10%) two hundred and forty two hundred and forty above data are tested under 25 ℃ on sea level
Export Markets︰
In the control circuit of radar, power supply, broadcasting, radio communication and electronic equipment.
