Vc7t62r air cooled triode /7t62r

Model No.︰	VC7T62R
Brand Name︰	GTVAC
Country of Origin︰	China
Unit Price︰	-
Minimum Order︰	1 pc

Total 26 Related Items

Product Description

Vc7t62r air-cooled triode is of cermet structure, thorium tungsten carbide cathode and forced air-cooled triode. The maximum anode dissipation power is 1500W. The maximum operating frequency is 50MHz. It is mainly used for high-frequency industrial oscillator and can be interchanged with 7t62r electronic tube produced by Toshiba Corporation of Japan.

Price Terms︰	FOB Wuxi
Specifications︰	Filament voltage 6.3±5%V Filament current 32A Amplification factor twenty-five Transconductance (ia=0.2adc) 6.3mA/V Interelectrode capacitance Grid anode 8.8pF Grid cathode 11pF Anode cathode 2.2pF Maximum operating frequency 50MHz Maximum height 170mm Maximum diameter 100mm weight 1400g Cooling mode Forced air cooling Minimum air volume 4.5m3/min Minimum static pressure 98Pa Maximum temperature of cooling air at inlet 45℃ External surface of anode and ceramic metal sealing 250℃
Advantages︰	Limit application data Continuous use Intermittent use Anode DC voltage (kV) seven point five seven point five Anode DC current (a) zero point seven five one Grid DC current (MA) two hundred three hundred Anode dissipation (W) one thousand and five hundred one thousand and five hundred Grid dissipation (W) seventy seventy Typical operating state of RF power amplifier or oscillator (Class C telegram) (oscillator) Continuous use Intermittent use Anode DC voltage (V) seven thousand seven thousand Anode DC current zero point seven zero point nine Grid DC current (MA) one hundred and fifty one hundred and eighty Grid resistance (Ω) three thousand three thousand Anode output power (W) three thousand and four hundred four thousand and five hundred Note: intermittent use refers to the condition that the working time is 10 seconds and the working ratio is 50%
Export Markets︰	Mainly used for high frequency industrial oscillator
Payment Details︰	Delivery upon payment
Min Order︰	1
Ship Date︰	two weeks later
