Gts24 solid state relay for motor

Model No.︰	GTS24电机用固态继电器
Brand Name︰	GTVAC
Country of Origin︰	China
Unit Price︰	-
Minimum Order︰	1 pc

Total 120 Related Items

Product Description

GTS24 is three-phase AC output relay (3PST-NO). The relay offer 4VDC to 32VDC input control, with outputs rated at 10A,15A,25A,40A or 60A. The relays includes a LED indicator to provide input status information. All models include an internal snubber. The relays provide 4000VAC opto-isolation, between input and output. Encapsulation, thermally conductive epoxy

Price Terms︰	FOB Wuxi
Specifications︰	INPUT（Ta=25℃） Control voltage range 4VDC to 32VAC Must operate voltage 4VDC Must release voltage 1VDC Max. input current 35mA Max.reverse protection voltage -32VDC OUTPUT（Ta=25℃） Load voltage range D-380:48VACto440VAC D-480:48VACto530VAC Load current range D-□□□A10Z:10A D-□□□A15Z:15A D-□□□A25Z:25A D-□□□A40Z:40A D-□□□A60Z:60A Max.transient overvoltage D-380:800Vpk D-480:1200Vpk Frequency range 47Hz to 63Hz Max. surge current(10ms) D-□□□A10Z:100Apk D-□□□A15Z:150Apk D-□□□A25Z:250Apk D-□□□A40Z:400Apk D-□□□A60Z:600Apk Max. I2t for fusing (10ms,A2s) D-□□□A10Z:50 D-□□□A15Z:112 D-□□□A25Z:312 D-□□□A40Z:800 D-□□□A60Z:1800 Max. on-state voltage drop 1.7Vr.m.s. Max. load current 100mA Max. leakage current 10mA Min. off-state dv/dt D-380:200V/μs D-480:500 V/μs Max. turn-on time Random turn-on 1ms Zero cross turn-on 1/2cycle +1ms Max. turn-off time 1/2cycle +1ms Max. power factor 0.5 GENERAL （Ta=25℃） Dielectric strength (input to output) 4000VAC,50Hz/60Hz, 1min Insulation resistance 1000MΩ(at 500VDC) Max. capacitance (input to output) 10pF Ambient temperature Operating -30℃ to 80℃ Srorage -30℃ to 100℃ Ambient humidity 45% to 85% RH Termination Screw Mounting model Panel mount Unit weight Approx.315g APPLICATION(Ta=25℃) Loadcurrent 10A 15A 25A 40A 50A 60A Motorpower 0.75kW 1.1kW 1.5kW 3kW 4kW 5kW Heatsink part number GT92B-150A GT92B-150C Cooling fan air flow 115CFM
Advantages︰	Features ●Photo isolation ●LED status indicator ●Dielectric strength 4000V ●zero cross or random turn-on ●Built-in snubber ●Removable finger proof cover available ●Panel mount ●Environmental friendly product（RoHS compliant）
Export Markets︰	It can be used in switching applications requiring ultra reliable, arc free and low power consumption. Other advantages of SSR include noiseless operation and compatibility with digital control circuits.
Payment Details︰	Delivery upon payment
Min Order︰	1
Ship Date︰	Two weeks later

Product Image
