1200A series ZLJ contactor

Model No.︰	1200A系列ZLJ型
Brand Name︰	GTVAC
Country of Origin︰	China
Unit Price︰	-
Minimum Order︰	10 pc

Total 23 Related Items

Product Description

Product code
coil
rated
Voltage (VDC)
20 ℃ amount
Constant voltage
Lower coil
electric current
（A）
Maximum current of 20 ℃ cold starting coil (a)
(20 ± 5) ℃,
Cold operating voltage (V)
electric
road
chart
appearance
Installation diagram
Pull in
（max）
Release (min)
ZLJ-1200S/24-48B
twenty-four
zero point five
five point four
twelve
one point two
Circuit diagram 1
Outline installation drawing 1
ZLJ-1200S/48-48B
forty-eight
zero point one
four point five
twenty-eight
two point four
Circuit diagram 1
Outline installation drawing 1
ZLJ-1200S/24-48B1
twenty-four
zero point five
five
twelve
one point two
Circuit diagram 2
Outline installation drawing 2
ZLJ-1200S/48-48B1
forty-eight
zero point one
four point two
twenty-eight
two point four
Circuit diagram 2
Outline installation drawing 2

Price Terms︰	FOB Wuxi
Specifications︰	order number Parameter name Product code 1200A series ZLJ contactor one Coil rated voltage (V DC) See product list two Coil current at 20 ℃ rated voltage (a) See product list three Maximum current of 20 ℃ cold starting coil (a) See product list four Rated voltage of main contact circuit (V DC) forty-eight five Rated load current of main contact circuit (a) one thousand and two hundred six Cold operating voltage (V) at (20 ± 5) ℃ See product list seven Power supply voltage fluctuation range ± 20% rated voltage eight Contact voltage drop of main contact under 100A load Not more than 80mv nine Maximum making and breaking capacity of main contact Make and break once, 4 times the rated load current, and the power on time is 5ms ten Maximum action time under rated voltage (MS) (coil without suppression) Pull in thirty release thirty eleven Maximum contact opening bounce time (MS) three twelve Electrical strength 1000V AC，50Hz，1min thirteen Electrical life（ τ＝ 0.001s) (Times) 10,000 fourteen Job specification continuity Remarks: products with auxiliary contact, auxiliary contact load 48V DC, 2A or 24V DC, 5A
Advantages︰	Service conditions Serial number entry name Product code 1200A series ZLJ contactor one ambient temperature （-25～+40）℃ two relative humidity + 98% at 20 ℃ three Vibration at fixed position 1～50Hz four Impact acceleration 30m/s2 five Installation position arbitrarily
Export Markets︰	use to start,stop,adjust and steer the accumulator-driven vehicles,also may be widely applied as power switching and on UPS in fields of traction,mineral machinery,petrochemical,metallurgy & marine,telecommunication and computer
Payment Details︰	Delivery upon payment
Min Order︰	10
Ship Date︰	two weeks later

Product Image
