QCC series magnetic blowing DC contactor

Model No.︰	QCC系列磁吹式直流接触器
Brand Name︰	GTVAC
Country of Origin︰	China
Unit Price︰	-
Minimum Order︰	-

Total 23 Related Items

Product Description

QCC Series of Magnetic Blow DC Contactors may be used to start,stop,adjust and steer the accumulator-driven vehicles,also may be widely applied as power switching and on UPS in fields of traction,mineral machinery,petrochemical,metallurgy & marine,telecommunication and computer.The contactors are in conformity with JB3974-85* Basic Technical Requirements on DC Appliance Used on Accumulator-Driven Vehicles*,and in conformity with standards of YD/T585-92*Commum ication Power Apparatus & Appliance*and YD/T512-92*Techincal Requirements for Power Equipment on Telegraply*

Specifications︰	◆ basic technical data Parameter name Coil rated voltage Coil rated current Rated load of main contact (a) Rated current of auxiliary contact (a) Parameters （VDC） (A) Loaded current rating Rated load current Code code coilvoltage Rating coilvoltage Rating at main contact of aux. Contact(A) QCC25-200A/11 12-48 ≤1 two hundred QCC26-400A/11 four hundred QCC28-160A/20 one hundred and sixty five QCC28-400A/20 four hundred five QCC29-160A/10 one hundred and sixty QCC29-400A/10 four hundred
Advantages︰	◆ use conditions required 1. Ambient temperature at installation location: -25~40 ℃ 2. Relative humidity:+20 ℃ up to 98% (up to 98% at 20 ℃) 3. Vibration frequency at the fixed position: F is 1-50HZ (1a=25/f frequency, a ＝ 250/f2 at 1-10hz, frequency 10~50hz) (1A=25/f freq，1-10Hz amp1 A=250/f2,freq.10~50Hz,amp1） 4. Shock vibration:acceleration not more than 30m/s2 5. Installation method: any mounting option
Export Markets︰	use to start,stop,adjust and steer the accumulator-driven vehicles,also may be widely applied as power switching and on UPS in fields of traction,mineral machinery,petrochemical,metallurgy & marine,telecommunication and computer
Payment Details︰	Delivery upon payment
Min Order︰	10
Ship Date︰	two weeks later

Product Image
